Technaxx Solar Balcony Power Plant 600W TX-220
Technaxx Solar Balcony Power Plant 600W TX-220

UVP: 999,00 EUR

EAN: 4260358125633

SKU: 5032

Solar Balcony Power Plant 600W TX-220


  • Attach to flat roof, terrace, balcony, fence and much more possibilities.
  • Easy installation: connect, start, save power
  • Lightweight and compact microinverter (hoymiles)
  • Suitable for feeding electricity into the 230V household grid
  • Maximum feed-in power of the inverter 600W
  • Ideal for covering the base load during the day in your home
  • MPP tracking for optimal power feeding
  • VDE compliant

    Technical specifications:
  • Solarpanel: Monocrystalline
  • Cable connection: MC4
  • Max. power: 325W
  • Operating voltage: 31.60V
  • Operating current: 10.29A
  • Module efficiency: 22.70%
  • Max. system voltage: 1000V
  • Operating temperature: -40°C ~ +85°C

  • Micro Inverter 600W
  • Nominal output power: 600VA
  • Nominal output current: 2.6A
  • Nominal output voltage: 230V
  • Operating temperature: -40°C - +65°C

    Balcony power plant Power Ø Power yield / year Ø Power yield / day
    600 Watt 570 kWh 1,56 kWh

    Solar Panel
  • 25-year limited warranty of 80% power output
  • 10-year mm warranty of 90% power output
  • 10-year limited warranty of materials and workmanship
    Micro Inverter
  • 12 years (144months) limited warranty

  • Package contents:
  • 1x PV Micro Inverter 600W,
  • 2x Solar module 325W,
  • 1x Betteri socket adapter,
  • 1x AC input end cap,
  • 1x 5m connection cable,
  • 1x user manual

    Optional accessory:
  • Balcony bracket TX-230

    Weight and Dimensions:
  • Weight device: 38kg
  • Dimensions device: 155.5 x 103.8 x 8cm
